In many homes, air conditioning and heating systems are essential but can be costly and complex to install and maintain. The window AC heat pump provides relief in the summer with cool air and warmth in the winter, saving both space and energy compared to traditional systems. This article will explain how window heat pumps work, their installation and maintenance, and whether they are a worthwhile investment for your home.
What Is a Window AC Heat Pump?
A window AC heat pump is a type of window air conditioner combining unit that can both cool and heat a room.
How Do Window AC Heat Pumps Work?
Window AC heat pumps operate using a refrigeration cycle that can be reversed depending on whether you need cooling or heating. Here's a breakdown of the process:
Cooling Mode
The heat pump draws warm air from the room and passes it over evaporator coils filled with refrigerant. The refrigerant absorbs the heat, causing it to evaporate and cool the air. The cooled air is then circulated back into the room, while the heated refrigerant is pumped outside where it releases the heat through the condenser coils.
Heating Mode
When switched to heating mode, the process reverses. The heat pump extracts heat from the outside air—even in cold weather—by passing air over the condenser coils. The refrigerant absorbs this heat, which is then transferred to the indoor air via the evaporator coils, warming the room.
Do Window AC Heat Pumps Work in Cold Climates?
Yes, window AC heat pumps can work and extract heat from the outside air in cold climates.
Normally, the heat pump extracts heat from the outside air. As the temperature gets lower, especially below 25°F (-4°C), the AC unit struggles to find enough heat in the outside air. When this happens, the Window AC heat pump system might rely on additional features like auxiliary heating or electric resistance heating to maintain heating level.
When the temperature drops, the performance of a window heat pump still decreases.
Decreased Heating Capacity
As outdoor temperatures fall, the unit’s heating capacity drops significantly. For example, a heat pump that operates at 100% efficiency at 50°F (10°C) may operate at only 60-70% efficiency when the temperature reaches 25°F (-4°C). The EER of window AC with a heat pump can drop from 12 to 8 on average.
Defrosting Cycles
In very cold weather, frost can build up on the outdoor coils, reducing the heat pump’s effectiveness. While most modern units include a defrost cycle to address this issue, it can cause brief interruptions in heating, reducing overall comfort for a short period.
How Much Noise Do Window AC Heat Pumps Make?
Window air conditioner heat pumps are generally quieter than traditional air conditioners or space heaters, but they still produce some noise during operation.
The noise level typically ranges between 40 to 60 decibels (dB), which is comparable to the sound of a conversation or a quiet office. The noise mainly comes from the compressor and fan, with higher noise levels occurring during defrost cycles or when the unit is working at full capacity.
If you're sensitive to this noise, you can look for models labeled as "low-noise" or "quiet operation", like Della's MIRI series Window AC, which has only 42 dB noise under mute mode.
Energy Efficiency of Window AC Heat Pumps
Typically, a window AC heat pump can have an EER (Energy Efficiency Ratio) of 10-12 in cooling mode and a COP (Coefficient of Performance) of 3-4 in heating mode. This means they deliver 3 to 4 times the amount of heating or cooling per unit of electricity consumed.
Window AC heat pumps are a cost-effective solution for homes in moderate climates. Their efficiency decreases in extreme temperatures, which can result in higher energy consumption. Nevertheless, they are still more energy-efficient than electric space heaters.
How to Install a Window AC Heat Pump?
Installing a window AC heat pump allows everyone DIY easily. Please follow these steps. This is the installation steps for Della Window AC but you can follow them on other units.
Check Window Requirements
Ensure the window width is between 25" and 36" (645-915 mm), and there is at least 14.5" (368 mm) of vertical clearance when the window is open. The frame should be sturdy enough to support the unit's weight.
Prepare the Unit
Remove all packaging and pre-assembled parts. Use the adhesive foam seal to line the upper window frame to prevent air leaks.
Position the Unit
With assistance, lift the AC unit onto the windowsill. Pull down the sash to secure the unit in place. Ensure the bottom rail of the unit is flush with the windowsill, and tilt the unit slightly downward (around 3°) to allow for proper drainage.
Secure the Side Panels
Extend and lock the side panels to fill any gaps between the unit and the window frame. Use locking pins or brackets as required.
Install Side Brackets
Attach the side brackets to the window frame using screws to prevent the unit from shifting. Tighten the upper screws first, followed by the lower ones.
Seal Remaining Gaps
Use additional foam seals or plasticene to fill any remaining gaps around the window and side panels, ensuring airtight installation.
Install the Security Bracket
For added safety, secure the top of the window sash with a security bracket using the provided screws.
Connect to Power
Plug the unit into a grounded outlet that meets the voltage requirements specified by the manufacturer.
Where Should You Not Put a Window AC Heat Pump?
When installing a window AC heat pump, place it where the inlet and outlet air pathways are even and unrestricted.
Additionally, do not position the unit near electrical devices, power outlets, kitchen cabinets, beds, sofas, or other valuables that could be damaged in case of water leakage or mechanical issues.
Proper clearance around the heat pump is crucial to prevent overheating, inefficiency, and potential hazards.
Window AC Heat Pump Maintenance
Regular maintenance and cleaning of the window AC heat pump is key to ensuring your window heat pump operates efficiently and lasts longer. Follow these steps for effective care:
Clean the Air Filter
-
Check the air filter monthly and clean it if needed to maintain airflow and efficiency.
-
Remove the grille from the front of the unit to access the filter.
-
Wash the filter with warm water and mild dish soap. Avoid using hot water above 104°F (40°C).
-
Let the filter dry completely before reinserting it. Alternatively, vacuum the filter to remove dust if washing is not preferred.
-
Never operate the unit without the filter, as it may damage the system.
Cabinet Cleaning
-
Keep the exterior of the unit clean.
-
Unplug the unit before cleaning to prevent electrical hazards.
-
Dust the cabinet with a soft, oil-free cloth or clean it with a damp cloth and mild soap. Rinse and dry thoroughly.
-
Avoid harsh cleaners, wax, or excessive water near the controls to prevent damage.
-
Check for Proper Drainage: Ensure that the unit is tilted slightly backward to allow proper water drainage, preventing water buildup that can cause noise or damage.
Winter Storage
-
If the heat pump is not used for an extended period:
-
Remove it from the window following the installation instructions.
-
Clean and dry the unit thoroughly before storing it in a cool, dry place.
-
Cover the unit with plastic or store it in its original box to protect it from dust and moisture.
Advantages of Window AC Heat Pumps
Energy Efficiency
Window heat pumps transfer heat instead of generating it, making them more energy-efficient than traditional heaters and air conditioners.
Cost-Effective
With dual heating and cooling functions, they eliminate the need for separate systems, reducing upfront and operating costs.
Space-Saving
Compact and easy to install, a small window AC with a heat pump fits neatly into your window without requiring extensive modifications or ductwork.
Year-Round Use
Provide both heating in winter and cooling in summer, making them versatile for different climates.
Disadvantages of Window AC Heat Pumps
Decreased Performance in Extreme Weather
Their efficiency drops in very cold (below 25°F/-4°C) or very hot conditions, potentially requiring backup systems.
Noise Levels
Although quieter than some alternatives, they may still produce noticeable noise, especially during high-capacity operation or defrost cycles.
Limited Coverage
Best suited for single rooms or small spaces, they may not be powerful enough for larger areas.
Aesthetic Concerns
Occupying a window can block natural light and affect the exterior appearance of your home.
What Features to Look for in a Window AC Heat Pump?
When choosing the best window air conditioner heat pump, consider these key features to ensure optimal performance and suitability for your needs:
Energy Efficiency
Look for units with a high EER (Energy Efficiency Ratio) or SEER (Seasonal Energy Efficiency Ratio) rating. Models with Energy Star certification like Della Window AC with EER 15 indicate lower operating costs and environmental benefits.
Heating and Cooling Capacity
Choose a unit with the appropriate BTU rating for your room size. A window AC unit with 10,000 BTUs is suitable for a room of approximately 450-550 square feet.
Noise Levels
Check the decibel (dB) rating. Units rated under 50 dB are quieter and more suitable for bedrooms or living spaces.
Dual Functionality
Ensure the unit has both heating and cooling modes and features such as automatic switching between the two for consistent comfort.
Programmable Thermostat
A digital thermostat or remote control allows precise temperature control, improving energy efficiency.
Defrost Feature
In colder climates, a built-in defrost function ensures reliable operation by preventing frost buildup on coils.
Air Filter and Maintenance Access
A washable air filter and easy-to-access components simplify maintenance and reduce long-term costs.
Smart Controls
Wi-Fi-enabled models offer remote operation through smartphone apps, making them more convenient to use.
Warranty and Support
Opt for units with a reliable warranty and accessible customer support to ensure peace of mind.
Are Window AC Heat Pumps Worth It?
Window AC heat pumps are an energy-efficient and cost-effective option for year-round climate control. They combine heating and cooling in one unit, making them ideal for smaller spaces or individual rooms. With relatively low installation costs and energy savings over time, they are a good choice for many homeowners.
